TAKAHASHI Air Powered Climber
Unique Features
- Zero sparking
- Compact and reliable with high power to weight ratio
- Minimal maintenance required
- No complicated air hoses connections
- Fully enclosed motor to prevent dust and dirt from entering climber
- Lower rope wear as there is only one sheave
- Built to withstand adverse environmental conditions
- Built in manual crank descent in case of power failure
- Usage counter installed in each clumber to ensure proper maintenance
| Item | Pneumatic Air Motor |
| Motor Type | Air Motor - Vane type |
| Power | Compressed Air |
| Climber Size | 340mm x 270mm x 300mm |
| Weight |
< 40KG (As compared to most brands at >48KG) |
| Lifting Capacity |
Up to 500KG Internal load test certificate can be provided. |
| Wire Rope | 8.3mm galvanised steel |
| Lifting Speed | 9m/min |
| Braking |
Two brakes are built into Climber. First brake: Air brake. Secondary brake: Mechanical brake with 1.85 times braking force. |
| Nominal Power | 1.6 HP |
| Nominal Speed | 1250 rpm |
| Idling Speed | 2500 rpm |
| Air Consumption | 1.6m3/min |
| Hose Internal Diameter | 19mm |
| Exhaust | G 3/4 " |
| Air Intake | G 1/2" |
| Max Air Pressure | 6 bar |
| Industries | Oil and gas and shipping where no sparking is compulsory |
